Overview
| Model No. | UCSTI |
| In Stock | Yes |
| Place of Original | China |
| Brand | GEE |
| Customs Code | 8535900090 |
| Warranty | 12 |
| Standard | IEC 60502.4 |
| Remarks | Quick installation and wide cross-section range,No shelf-life issues |
Description
SKU Description
| UCSTI-15-A | 15KV(8.7/15KV), Cross section: 25-50mm², Creepage distance: 256mm, Cable insulation OD: 16.0-18.7mm |
| UCSTI-15-B | 15KV(8.7/15KV), Cross section: 70-120mm², Creepage distance: 256mm, Cable insulation OD: 20.0-23.3mm |
| UCSTI-15-C | 15KV(8.7/15KV), Cross section: 150-240mm², Creepage distance: 256mm, Cable insulation OD: 24.5-28.5mm |
| UCSTI-15-D | 15KV(8.7/15KV), Cross section: 300-400mm², Creepage distance: 256mm, Cable insulation OD: 30.4-33.4mm |
| UCSTI-24-A | 24KV(10/20KV), Cross section: 35-50mm², Creepage distance: 310mm, Cable insulation OD: 19.5-22.0mm |
| UCSTI-24-B | 24KV(10/20KV), Cross section: 70-150mm², Creepage distance: 310mm, Cable insulation OD: 23.6-27.9mm |
| UCSTI-24-C | 24KV(10/20KV), Cross section: 185-400mm², Creepage distance: 310mm, Cable insulation OD: 30.4-35.4mm |
| UCSTI-36-A | 36KV(18/30KV), Cross section: 35-70mm², Creepage distance: 650mm, Cable insulation OD: 21.5-27.0mm |
| UCSTI-36-B | 36KV(18/30KV), Cross section: 95-185mm², Creepage distance: 650mm, Cable insulation OD: 28.6-32.9mm |
| UCSTI-36-C | 36KV(18/30KV), Cross section: 240-400mm², Creepage distance: 650mm, Cable insulation OD: 35.4-40.4mm |
